Polycrystalline Solar Panel

Home > Products > Solar Panel > Polycrystalline Solar Panel

Multiple Cut Cells Poly

Global warming threatens the survival of human society, as well as the survival of countless species. Luckily, decades of research have led to efficient solar panel systems that create electricity without producing global warming pollution.

Product Feature

Benefits of Solar Panels

1.Solar power provides energy reliability

The rising and setting of the sun is extremely consistent. All across the world, we know exactly when it will rise and set every day of the year, this makes solar power an extremely reliable source of energy.


2.Cut-down electricity bill

The key reason that most households convert their power source to solar energy is to cut down their electrical bill because the electrical usage generated from the sun is free.By converting as many home appliances as possible to use solar energy,you can save a significant savings in your utilities expenses.


3.Low/no maintenance needed once you have installed the solar power system, it can last twenty to thirty years without major maintenance needed. You may need to check system once a year, just to make sure everything is performing as it should. Since it requires very minimum maintenance cost, your cost should be minimal.


4.Solar power provides energy independence

Solar power provides the great benefit of energy independence. Again, the “fuel” for solar panels cannot be bought or monopolized. It is free for all to use. Once you have solar panels on your roof, you have an essentially independent source of electricity that is all yours. This is important for individuals, but also for cities, counties, states, countries, and even companies.


5.Solar power helps to slow global warming Global warming threatens the survival of human society, as well as the survival of countless species. Luckily, decades of research have led to efficient solar panel systems that create electricity without producing global warming pollution.


Features

1.Rural electricity applications

2.Residential roof-top on grid and off-grid system

3.Other on-grid and off-grid applications

4.Large on-grid solar power stations

5.Commercial/industrial roof-top systems

6.Agriculture solar system

Detail Show

POLY CRYSTALLINE SOLAR PANEL



ELECTRICAL SPECIFICATION
RT003PRT005PRT010PRT020PRT030PRT040PRT050PRT060PRT080P
Nominal Maximum Power3W5W10W20W30W40W50W60W80W
Open Circuit Voltage Voc(V)10.8V10.8V22V21.9V21.9V21.5V21.9V22V20.3V
Short Circuit Current Isc(A)0.37A0.62A0.61A1.23A1.85A2.51A3.09A3.68A5.33A
Peak Voltage Vmp(V)8.8V8.8V17.9V17.8V17.8V17.5V17.8V17.9V16.5V
Peak Current Imp(A)0.34A0.57A0.56A1.12A1.69A2.29A2.81A3.35A4.85A
Operating Temperature-40℃~+85℃
Maximum System Voltage1000V( IEC)/ 600V( UL)
Maximum Series Fuse Rating15A
Application ClassificationClassA
Power Tolerance±3%
Temperature Cofficient
Pmax-0.45/℃
Voc-0.35/℃
Isc-0.060/℃
NOCT45/℃
Mechanical Data
Cell Type52*19.578*2652*39156*22.28156*39156*52156*52156*65156*91
Cell Arrangement(mm)3*62*94*92*184*94*93*123*123*11
Dimensions(mm)185*185*17300*190*17420*260*17540*350*25680*430*25680*547*30736*545*30890*545*301080*545*35
Weight(kg)0.340.671.161.683.964.855.97
Front CoverTempered glass
Frame materialAnodized aluminium alloy
Standard Packagingtt20pcs20pcs10pcs10pcs2pcs
